SKF 6314M/C3
Price: 250.50 $
Specifications
| Brand | SKF |
| Item Number | 6314M/C3 SKF |
| EAN | 7316570689211 |
| Category | Deep Groove Ball Bearings Single Row |
| Inner (d) MM | 70 |
| Outer (D) MM | 150 |
| Width (B) MM | 35 |
| Inner (d) Inch | 2.7559 |
| Outer (D) Inch | 5.9055 |
| Width (B) Inch | 1.378 |
| Weight (kg) | 3.125 kg |
| Bore | C - Cylindrical Bore |
| Seal | No Seal |
| Cage Type | M - Brass Cage |
| External Modification | No External Modification |
| Radial Internal Play | C3 Internal Play (Higher than Cn) |
| Precision | Standard Precision |
| Lubrication | Standard Lubrication |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Special Treatment | No Special Treatment |
| M | Machined Brass Cage, Ball Centered; Different Designs And Material Grades Are Identified By A Figure Following The M, e.g. M2 |
| C3 | Internal Clearance Larger Than Normal |
FAG 6314ZRN
2.59 kg
70x150x35 mm
FAG 6314N-M-C3
3.095 kg
70x150x35 mm
FAG 6314-N-C3
2.49 kg
70x150x35 mm
FAG 6314-J20AB-C3
2.52 kg
70x150x35 mm
FAG 6314-2Z-L207-C3
2.62 kg
70x150x35 mm
FAG 6314-C4
2.49 kg
70x150x35 mm
FAG 6314-MA-C3
3.125 kg
70x150x35 mm
FAG 6314-M-C3
3.125 kg
70x150x35 mm
FAG 6314-Z
2.585 kg
70x150x35 mm
FAG 6314-Z-N
2.59 kg
70x150x35 mm
FAG 6314-2Z-C4
2.615 kg
70x150x35 mm
FAG HC6314-2Z-L038-C3
2.615 kg
70x150x35 mm
FAG 6314-M
3.125 kg
70x150x35 mm
FAG 6314-2Z-C3
2.615 kg
70x150x35 mm
FAG 6314-J20AA-C3
2.62 kg
70x150x35 mm
FAG 6314-RSR
2.82 kg
70x150x35 mm
FAG 6314-2Z
2.615 kg
70x150x35 mm
FAG 6314-J20C-C3
2.52 kg
70x150x35 mm
FAG 6314-RSR-C3
2.82 kg
70x150x35 mm
FAG 6314-Z-N-C3
2.59 kg
70x150x35 mm
FAG 6314-2RSR
2.82 kg
70x150x35 mm
FAG 6314-C3
2.52 kg
70x150x35 mm
FAG 6314-H-2RSR-SN-C3
2.82 kg
70x150x35 mm
FAG 6314-Z-C3
2.59 kg
70x150x35 mm
FAG 6314-M-J20AA-C3
3.125 kg
70x150x35 mm
FAG 6314-M-C4
3.125 kg
70x150x35 mm
FAG 6314-2RSR-C3
2.82 kg
70x150x35 mm
FAG 6314-2Z-L237-C3
2.615 kg
70x150x35 mm
FAG 6314-N
2.49 kg
70x150x35 mm
FAG 6314-M-P6
3.125 kg
70x150x35 mm
FAG 6314-M-P6-C4
3.125 kg
70x150x35 mm
SKF 6314-2Z/C3WT
2.615 kg
70x150x35 mm
SKF 6314-2RS1/C3
2.82 kg
70x150x35 mm
SKF 6314MC/P52
3.125 kg
70x150x35 mm
