FAG 6314-Z-N

FAG 6314-Z-N
FAG 6314-Z-N rulman resim 1
FAG 6314-Z-N rulman resim 2
Price: 198.89 $
Specifications
Brand FAG
Item Number 6314-Z-N FAG
Manufacturer Part Number 0191109950000
EAN 4012801280600
Category Deep Groove Ball Bearings Single Row
Weight and Dimensions
Inner (d) MM 70
Outer (D) MM 150
Width (B) MM 35
Inner (d) Inch 2.7559
Outer (D) Inch 5.9055
Width (B) Inch 1.378
Weight (kg) 2.59 kg
Product Properties
Bore C - Cylindrical Bore
Seal Z - Steel Seal on One Side
Cage Type S - Steel or Standard Cage
External Modification N - Snap Ring Groove in Outer Ring
Radial Internal Play Cn Normal Internal Play
Precision Standard Precision
Lubrication Standard Lubrication
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Width (b) mm 35
Basic static load rating, radial (C 0r) 69000
Limiting speed (n G) 6800
Reference speed (n u03d1r) 6100
ECLASS number 23-05-08-01
ECLASS2 number 23-05-08-01
Suffix description
Z Shield Of Pressed Sheet Steel On One Side Of The Bearing
N Snap Ring Groove In The Outer Ring
