FAG 6314-M
Price: 226.58 $
Specifications
| Brand | FAG |
| Item Number | 6314-M FAG |
| Manufacturer Part Number | 0191108390000 |
| EAN | 4012801205627 |
| Category | Deep Groove Ball Bearings Single Row |
| Inner (d) MM | 70 |
| Outer (D) MM | 150 |
| Width (B) MM | 35 |
| Inner (d) Inch | 2.7559 |
| Outer (D) Inch | 5.9055 |
| Width (B) Inch | 1.378 |
| Weight (kg) | 3.125 kg |
| Bore | C - Cylindrical Bore |
| Seal | No Seal |
| Cage Type | M - Brass Cage |
| External Modification | No External Modification |
| Radial Internal Play | Cn Normal Internal Play |
| Precision | Standard Precision |
| Lubrication | Standard Lubrication |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Special Treatment | No Special Treatment |
| Width (b) mm | 35 |
| Radial Static Load Rating C0r (N) | 69000 |
| Radial Dynamic Load Rating Cr (N) | 115000 |
| Basic static load rating, radial (C 0r) | "69000.0000" |
| Limiting speed (n G) | 8800 |
| Reference speed (n u03d1r) | 6100 |
| ECLASS number | 23-05-08-01 |
| ECLASS2 number | 23-05-08-01 |
| Medias description | Deep groove ball bearing 63..-M, single row, cf. DIN 625-1 |
| M | Solid Brass Cage, Ball-Guided |
