FAG 6314-H-2RSR-SN-C3
Price: 94.52 $
Specifications
| Brand | FAG |
| Item Number | 6314-H-2RSR-SN-C3 FAG |
| Category | Deep Groove Ball Bearings Single Row |
| Inner (d) MM | 70 |
| Outer (D) MM | 150 |
| Width (B) MM | 35 |
| Inner (d) Inch | 2.7559 |
| Outer (D) Inch | 5.9055 |
| Width (B) Inch | 1.378 |
| Weight (kg) | 2.82 kg |
| Bore | C - Cylindrical Bore |
| Seal | 2RS - Rubber Seal on Two Sides |
| Cage Type | S - Steel or Standard Cage |
| External Modification | No External Modification |
| Radial Internal Play | C3 Internal Play (Higher than Cn) |
| Precision | Standard Precision |
| Lubrication | Standard Lubrication |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Special Treatment | No Special Treatment |
| Width (b) mm | 35 |
| Radial Static Load Rating C0r (N) | 68040 |
| Radial Dynamic Load Rating Cr (N) | 104130 |
| Basic static load rating, radial (C 0r) | "68040.0000" |
| Limiting speed (n G) | 2800 |
| ECLASS number | 23-05-08-01 |
| ECLASS2 number | 23-05-08-01 |
| Medias description | Deep groove ball bearings 63..-H-2RSR, main dimensions to DIN 625-1, lip seals on both sides |
| H | Basic Quality |
| 2RSR | Rubber Seals At Each Side Of The Bearing |
| SN | The Rings Of The Bearing Are Dimensional Stabilised To 120°C |
| C3 | Internal Clearance Larger Than Normal |
