SKF 6314-2RS1/C3WT
Price: 204.93 $
Specifications
| Brand | SKF |
| Item Number | 6314-2RS1/C3WT SKF |
| Also known as |
6314-2RS1/C3 |
| EAN | 7316571752716 |
| Category | Deep Groove Ball Bearings Single Row |
| Inner (d) MM | 70 |
| Outer (D) MM | 150 |
| Width (B) MM | 35 |
| Inner (d) Inch | 2.7559 |
| Outer (D) Inch | 5.9055 |
| Width (B) Inch | 1.378 |
| Weight (kg) | 2.82 kg |
| Bore | C - Cylindrical Bore |
| Seal | 2RS - Rubber Seal on Two Sides |
| Cage Type | S - Steel or Standard Cage |
| External Modification | No External Modification |
| Radial Internal Play | C3 Internal Play (Higher than Cn) |
| Precision | Standard Precision |
| Lubrication | High Temperature Grease |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Special Treatment | No Special Treatment |
| 2RS1 | Sheet Steel Reinforced Contact Seal Of Acrylonitrile-Butadiene Rubber (NBR) On Both Sides Of The Bearing |
| C3 | Internal Clearance Larger Than Normal |
| WT | Grease Fill For Low As Well As High Temperature e.g. -40 ~ 160°C. WT Or A Two-Figure Number Following WT Identifies The Actual Grease. An Additional Letter Or Letter/ Figure Combination As Mentioned Under u201cHTu201d Identifies Filling Degrees Other Than Standard |
