FAG QJ304-XL-MPA-T42B

FAG QJ304-XL-MPA-T42B
FAG QJ304-XL-MPA-T42B rulman resim 1
FAG QJ304-XL-MPA-T42B rulman resim 2
FAG QJ304-XL-MPA-T42B rulman resim 3
FAG QJ304-XL-MPA-T42B rulman resim 4
FAG QJ304-XL-MPA-T42B rulman resim 5
Price: 62.59 $
Specifications
Brand FAG
Item Number QJ304-XL-MPA-T42B FAG
Manufacturer Part Number 0192615944381
Also known as QJ304-MPA-T42B
EAN 4012801987257
Category Four Point Contact Ball Bearing
Weight and Dimensions
Inner (d) MM 20
Outer (D) MM 52
Width (B) MM 15
Inner (d) Inch 0.7874
Outer (D) Inch 2.0472
Width (B) Inch 0.5906
Weight (kg) 0.18 kg
Product Properties
Seal No Seal
Cage Type MA - Brass Cage, Centered on Outer Ring
External Modification No External Modification
Radial Internal Play Cn Normal Internal Play
Precision Special Axial Clearance
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring Split inner ring
Data from Schaeffler (medias)
Width (b) mm 15
Radial Static Load Rating C0r (N) 19600
Radial Dynamic Load Rating Cr (N) 31000
Basic static load rating, radial (C 0r) "19600.0000"
Limiting speed (n G) 28500
Reference speed (n u03d1r) 10700
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Four-point contact bearing QJ3..-XL-MPA, inner ring split
Suffix description
XL X-Life
MPA Solid Brass Cage
T42B Four Point Bearings With Special Axial Clearance
