FAG 6304-TVH-C3

FAG 6304-TVH-C3
FAG 6304-TVH-C3 rulman resim 1
FAG 6304-TVH-C3 rulman resim 2
FAG 6304-TVH-C3 rulman resim 3
FAG 6304-TVH-C3 rulman resim 4
Price: 5.52 $
Specifications
Brand FAG
Item Number 6304-TVH-C3 FAG
Manufacturer Part Number 0383771790030
EAN 4012801563994
Category Deep Groove Ball Bearings Single Row
Weight and Dimensions
Inner (d) MM 20
Outer (D) MM 52
Width (B) MM 15
Inner (d) Inch 0.7874
Outer (D) Inch 2.0472
Width (B) Inch 0.5906
Weight (kg) 0.144 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type P - Plastic Molded Cage
External Modification No External Modification
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Lubrication Standard Lubrication
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Width (b) mm 15
Radial Static Load Rating C0r (N) 7900
Radial Dynamic Load Rating Cr (N) 16900
Basic static load rating, radial (C 0r) "7900.0000"
Limiting speed (n G) 19800
Reference speed (n u03d1r) 14400
ECLASS number 23-05-08-01
ECLASS2 number 23-05-08-01
Medias description Deep groove ball bearing 63..-TVH, single row, cf. DIN 625-1
Suffix description
TVH Solid Cage Made From Glass Fibre Reinforced Polyamide 66
C3 Internal Clearance Larger Than Normal
