FAG 6304-2Z-L207-C3

FAG 6304-2Z-L207-C3
FAG 6304-2Z-L207-C3 rulman resim 1
FAG 6304-2Z-L207-C3 rulman resim 2
FAG 6304-2Z-L207-C3 rulman resim 3
FAG 6304-2Z-L207-C3 rulman resim 4
Price: 14.03 $
Specifications
Brand FAG
Item Number 6304-2Z-L207-C3 FAG
Category Deep Groove Ball Bearings Single Row
Weight and Dimensions
Inner (d) MM 20
Outer (D) MM 52
Width (B) MM 15
Inner (d) Inch 0.7874
Outer (D) Inch 2.0472
Width (B) Inch 0.5906
Weight (kg) 0.146 kg
Product Properties
Bore C - Cylindrical Bore
Seal ZZ/2Z - Steel Seal on Two Sides
Cage Type S - Steel or Standard Cage
External Modification No External Modification
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Lubrication 2 - High Temperature Grease
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Radial Static Load Rating C0r (N) 7900
Radial Dynamic Load Rating Cr (N) 16900
ECLASS number 23-05-08-01
ECLASS2 number 23-05-08-01
Medias description Deep groove ball bearing 63..-2Z, single row, cf. DIN 625-1
Suffix description
2Z Non-Contact Sealing Shield On Both Sides (Sheet Metal Gap Seal)
L207 Grease Filling With Arcanol L207 (High Temperature Grease)
C3 Internal Clearance Larger Than Normal
