FAG QJ304-XL-MPA-T42B Image 2
Visual product photo and picture of the product.
Price: 62.59 $
Specifications
Weight and Dimensions
| Inner (d) MM |
20 |
| Outer (D) MM |
52 |
| Width (B) MM |
15 |
| Inner (d) Inch |
0.7874 |
| Outer (D) Inch |
2.0472 |
| Width (B) Inch |
0.5906 |
| Weight (kg) |
0.18 kg
|
Product Properties
| Seal |
No Seal |
| Cage Type |
MA - Brass Cage, Centered on Outer Ring |
| External Modification |
No External Modification |
| Radial Internal Play |
Cn Normal Internal Play |
| Precision |
Special Axial Clearance |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring |
Split inner ring |
Data from Schaeffler (medias)
| Width (b) mm |
15 |
| Radial Static Load Rating C0r (N) |
19600 |
| Radial Dynamic Load Rating Cr (N) |
31000 |
| Basic static load rating, radial (C 0r) |
"19600.0000" |
| Limiting speed (n G) |
28500 |
| Reference speed (n u03d1r) |
10700 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Four-point contact bearing QJ3..-XL-MPA, inner ring split |
Suffix description
| XL |
X-Life |
| MPA |
Solid Brass Cage |
| T42B |
Four Point Bearings With Special Axial Clearance |
