FAG QJ220-N2-MPA-C4

FAG QJ220-N2-MPA-C4
FAG QJ220-N2-MPA-C4 rulman resim 1
FAG QJ220-N2-MPA-C4 rulman resim 2
FAG QJ220-N2-MPA-C4 rulman resim 3
FAG QJ220-N2-MPA-C4 rulman resim 4
Price: 449.10 $
Specifications
Brand FAG
Item Number QJ220-N2-MPA-C4 FAG
Manufacturer Part Number 0167423460040
EAN 4012802157444
Category Four Point Contact Ball Bearing
Weight and Dimensions
Inner (d) MM 100
Outer (D) MM 180
Width (B) MM 34
Inner (d) Inch 3.937
Outer (D) Inch 7.0866
Width (B) Inch 1.3386
Weight (kg) 3.95 kg
Product Properties
Seal No Seal
Cage Type MA - Brass Cage, Centered on Outer Ring
External Modification N2 - 2 Locking Groove in Outer Ring
Radial Internal Play C4 Internal Play (Higher than C3)
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring Split inner ring
Data from Schaeffler (medias)
Width (b) mm 34
Radial Static Load Rating C0r (N) 241000
Radial Dynamic Load Rating Cr (N) 224000
Basic static load rating, radial (C 0r) "241000.0000"
Limiting speed (n G) 6600
Reference speed (n u03d1r) 3550
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Four-point contact bearing QJ2..-N2-MPA, inner ring split
Suffix description
N2 Two Locating Slots (Notches) 180° Apart In One Outer Ring Side Face Or Housing Washer
MPA Window-Type Machined Brass Cage; Guidance By The Outer Ring (Housing)
C4 Bearing Internal Clearance Greater Than C3
