FAG 6220-M-J20AA-C3

FAG 6220-M-J20AA-C3
FAG 6220-M-J20AA-C3 rulman resim 1
FAG 6220-M-J20AA-C3 rulman resim 2
FAG 6220-M-J20AA-C3 rulman resim 3
FAG 6220-M-J20AA-C3 rulman resim 4
Price: 721.60 $
Specifications
Brand FAG
Item Number 6220-M-J20AA-C3 FAG
Manufacturer Part Number 0390140290030
EAN 4054364843045
Category Deep Groove Ball Bearings Single Row
Weight and Dimensions
Inner (d) MM 100
Outer (D) MM 180
Width (B) MM 34
Inner (d) Inch 3.937
Outer (D) Inch 7.0866
Width (B) Inch 1.3386
Weight (kg) 3.8 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type M - Brass Cage
External Modification No External Modification
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Breakdown Voltage 1000v
Lubrication Standard Lubrication
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Width (b) mm 34
Radial Static Load Rating C0r (N) 93000
Radial Dynamic Load Rating Cr (N) 130000
Basic static load rating, radial (C 0r) "93000.0000"
Limiting speed (n G) 6500
Reference speed (n u03d1r) 4800
ECLASS number 23-05-08-01
ECLASS2 number 23-05-08-01
Medias description Deep groove ball bearing 62..-M-J20AA, single row, cf. DIN 625-1
Suffix description
M Solid Brass Cage, Ball-Guided
J20AA Coating Which Consists Of Oxide Ceramic, It Is Applied By Plasma Spraying And Then Sealed With Synthetic Resin. Speciality Humid Environments
C3 Internal Clearance Larger Than Normal
