FAG 6220-2Z

FAG 6220-2Z
FAG 6220-2Z rulman resim 1
FAG 6220-2Z rulman resim 2
FAG 6220-2Z rulman resim 3
FAG 6220-2Z rulman resim 4
Price: 112.33 $
Specifications
Brand FAG
Item Number 6220-2Z FAG
Manufacturer Part Number 0167216830000
EAN 4012801203654
Category Deep Groove Ball Bearings Single Row
Weight and Dimensions
Inner (d) MM 100
Outer (D) MM 180
Width (B) MM 34
Inner (d) Inch 3.937
Outer (D) Inch 7.0866
Width (B) Inch 1.3386
Weight (kg) 3.26 kg
Product Properties
Bore C - Cylindrical Bore
Seal ZZ/2Z - Steel Seal on Two Sides
Cage Type S - Steel or Standard Cage
External Modification No External Modification
Radial Internal Play Cn Normal Internal Play
Precision Standard Precision
Lubrication Standard Lubrication
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Width (b) mm 34
Radial Static Load Rating C0r (N) 93000
Radial Dynamic Load Rating Cr (N) 130000
Basic static load rating, radial (C 0r) "93000.0000"
Limiting speed (n G) 4250
Reference speed (n u03d1r) 4800
ECLASS number 23-05-08-01
ECLASS2 number 23-05-08-01
Medias description Deep groove ball bearing 62..-2Z, single row, cf. DIN 625-1
Suffix description
2Z Non-Contact Sealing Shield On Both Sides (Sheet Metal Gap Seal)
