FAG 6220-M-J20AA-C4
Price: 734.25 $
Specifications
| Brand | FAG |
| Item Number | 6220-M-J20AA-C4 FAG |
| Manufacturer Part Number | 0390140290040 |
| EAN | 4012802354386 |
| Category | Deep Groove Ball Bearings Single Row |
| Inner (d) MM | 100 |
| Outer (D) MM | 180 |
| Width (B) MM | 34 |
| Inner (d) Inch | 3.937 |
| Outer (D) Inch | 7.0866 |
| Width (B) Inch | 1.3386 |
| Weight (kg) | 3.8 kg |
| Bore | C - Cylindrical Bore |
| Seal | No Seal |
| Cage Type | M - Brass Cage |
| External Modification | No External Modification |
| Radial Internal Play | C4 Internal Play (Higher than C3) |
| Precision | Breakdown Voltage 1000v |
| Lubrication | Standard Lubrication |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Special Treatment | No Special Treatment |
| Width (b) mm | 34 |
| Radial Static Load Rating C0r (N) | 93000 |
| Radial Dynamic Load Rating Cr (N) | 130000 |
| Basic static load rating, radial (C 0r) | "93000.0000" |
| Limiting speed (n G) | 6500 |
| Reference speed (n u03d1r) | 4800 |
| ECLASS number | 23-05-08-01 |
| ECLASS2 number | 23-05-08-01 |
| Medias description | Deep groove ball bearing 62..-M-J20AA, single row, cf. DIN 625-1 |
| M | Solid Brass Cage, Ball-Guided |
| J20AA | Coating Which Consists Of Oxide Ceramic, It Is Applied By Plasma Spraying And Then Sealed With Synthetic Resin. Speciality Humid Environments |
| C4 | Bearing Internal Clearance Greater Than C3 |
