FAG NU308-E-XL-JP3-C3

FAG NU308-E-XL-JP3-C3
FAG NU308-E-XL-JP3-C3 rulman resim 1
FAG NU308-E-XL-JP3-C3 rulman resim 2
FAG NU308-E-XL-JP3-C3 rulman resim 3
FAG NU308-E-XL-JP3-C3 rulman resim 4
Price: 47.18 $
Specifications
Brand FAG
Item Number NU308-E-XL-JP3-C3 FAG
Manufacturer Part Number 0389991100030
Also known as NU308-E-JP3-C3
EAN 4012802189261
Category Cylindrical Roller Bearing Single Row
Weight and Dimensions
Inner (d) MM 40
Outer (D) MM 90
Width (B) MM 23
Inner (d) Inch 1.5748
Outer (D) Inch 3.5433
Width (B) Inch 0.9055
Weight (kg) 0.66 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type S - Steel or Standard Cage
External Modification No External Modification
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Data from Schaeffler (medias)
ECLASS number 23-05-09-01
ECLASS2 number 23-05-09-01
Suffix description
E Increased Load Capacity
XL X-Life
JP3 Applications With Cylindrical Roller Bearings With A Bearing Outer Diameter >90mm Wil Contain JP3 Sheet Steel Cage With Optimized Sheet Thickness, Improved Roller Guidance And Roller Retention, And Increased Oil Or Grease Flow
C3 Internal Clearance Larger Than Normal
