FAG 6308-Z-C3

FAG 6308-Z-C3
FAG 6308-Z-C3 rulman resim 1
FAG 6308-Z-C3 rulman resim 2
FAG 6308-Z-C3 rulman resim 3
FAG 6308-Z-C3 rulman resim 4
Price: 21.36 $
Specifications
Brand FAG
Item Number 6308-Z-C3 FAG
Manufacturer Part Number 0167234900030
Also known as 6308-C-Z-C3
EAN 4012801075428
Category Deep Groove Ball Bearings Single Row
Weight and Dimensions
Inner (d) MM 40
Outer (D) MM 90
Width (B) MM 23
Inner (d) Inch 1.5748
Outer (D) Inch 3.5433
Width (B) Inch 0.9055
Weight (kg) 0.638 kg
Product Properties
Bore C - Cylindrical Bore
Seal Z - Steel Seal on One Side
Cage Type S - Steel or Standard Cage
External Modification No External Modification
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Lubrication Standard Lubrication
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Width (b) mm 23
Radial Static Load Rating C0r (N) 25000
Radial Dynamic Load Rating Cr (N) 45500
Basic static load rating, radial (C 0r) "25000.0000"
Limiting speed (n G) 10800
Reference speed (n u03d1r) 9000
ECLASS number 23-05-08-01
ECLASS2 number 23-05-08-01
Medias description Deep groove ball bearing 63..-Z, single row, cf. DIN 625-1
Suffix description
Z Shield Of Pressed Sheet Steel On One Side Of The Bearing
C3 Internal Clearance Larger Than Normal
