FAG 6308-M-J20AA-C4

FAG 6308-M-J20AA-C4
FAG 6308-M-J20AA-C4 rulman resim 1
FAG 6308-M-J20AA-C4 rulman resim 2
FAG 6308-M-J20AA-C4 rulman resim 3
FAG 6308-M-J20AA-C4 rulman resim 4
Price: 365.15 $
Specifications
Brand FAG
Item Number 6308-M-J20AA-C4 FAG
Manufacturer Part Number 0605728920040
Also known as 6308M/C4VL0241
EAN 4012802341584
Category Deep Groove Ball Bearings Single Row
Weight and Dimensions
Inner (d) MM 40
Outer (D) MM 90
Width (B) MM 23
Inner (d) Inch 1.5748
Outer (D) Inch 3.5433
Width (B) Inch 0.9055
Weight (kg) 0.765 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type M - Brass Cage
External Modification No External Modification
Radial Internal Play C4 Internal Play (Higher than C3)
Precision Breakdown Voltage 1000v
Lubrication Standard Lubrication
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Width (b) mm 23
Basic static load rating, radial (C 0r) 25000
Limiting speed (n G) 14000
Reference speed (n u03d1r) 9000
ECLASS number 23-05-08-01
ECLASS2 number 23-05-08-01
Suffix description
M Solid Brass Cage, Ball-Guided
J20AA Coating Which Consists Of Oxide Ceramic, It Is Applied By Plasma Spraying And Then Sealed With Synthetic Resin. Speciality Humid Environments
C4 Bearing Internal Clearance Greater Than C3
