FAG 6308-2Z

FAG 6308-2Z
FAG 6308-2Z rulman resim 1
FAG 6308-2Z rulman resim 2
FAG 6308-2Z rulman resim 3
FAG 6308-2Z rulman resim 4
FAG 6308-2Z rulman resim 5
Price: 12.04 $
Specifications
Brand FAG
Item Number 6308-2Z FAG
Manufacturer Part Number 0167234060000
Also known as 6308-C-2Z
EAN 4012801078122
Category Deep Groove Ball Bearings Single Row
Weight and Dimensions
Inner (d) MM 40
Outer (D) MM 90
Width (B) MM 23
Inner (d) Inch 1.5748
Outer (D) Inch 3.5433
Width (B) Inch 0.9055
Weight (kg) 0.643 kg
Product Properties
Bore C - Cylindrical Bore
Seal ZZ/2Z - Steel Seal on Two Sides
Cage Type S - Steel or Standard Cage
External Modification No External Modification
Radial Internal Play Cn Normal Internal Play
Precision Standard Precision
Lubrication Standard Lubrication
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Width (b) mm 23
Radial Static Load Rating C0r (N) 25000
Radial Dynamic Load Rating Cr (N) 45500
Basic static load rating, radial (C 0r) "25000.0000"
Limiting speed (n G) 9100
Reference speed (n u03d1r) 9000
ECLASS number 23-05-08-01
ECLASS2 number 23-05-08-01
Medias description Deep groove ball bearing 63..-2Z, single row, cf. DIN 625-1
Suffix description
2Z Non-Contact Sealing Shield On Both Sides (Sheet Metal Gap Seal)
