FAG NJ220-E-XL-M1-C3

FAG NJ220-E-XL-M1-C3
FAG NJ220-E-XL-M1-C3 rulman resim 1
FAG NJ220-E-XL-M1-C3 rulman resim 2
FAG NJ220-E-XL-M1-C3 rulman resim 3
FAG NJ220-E-XL-M1-C3 rulman resim 4
Price: 366.28 $
Specifications
Brand FAG
Item Number NJ220-E-XL-M1-C3 FAG
Manufacturer Part Number 0167348310030
Also known as NJ220-E-M1-C3
EAN 4012801228015
Category Cylindrical Roller Bearing Single Row
Weight and Dimensions
Inner (d) MM 100
Outer (D) MM 180
Width (B) MM 34
Inner (d) Inch 3.937
Outer (D) Inch 7.0866
Width (B) Inch 1.3386
Weight (kg) 3.83 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type M - Brass Cage
External Modification No External Modification
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Data from Schaeffler (medias)
Width (b) mm 34
Radial Static Load Rating C0r (N) 305000
Radial Dynamic Load Rating Cr (N) 295000
Basic static load rating, radial (C 0r) "305000.0000"
Limiting speed (n G) 6800
Reference speed (n u03d1r) 3450
ECLASS number 23-05-09-01
ECLASS2 number 23-05-09-01
Medias description Cylindrical roller bearing NJ..-E-XL-M1, with cage, single row, semi-locating bearing, 2 ribs on outer ring, 1 rib on inner ring, type NJ
Suffix description
E Increased Load Capacity
XL X-Life
M1 Solid Brass Cage, Two Piece, Roller Guided
C3 Internal Clearance Larger Than Normal
