FAG N314-E-XL-TVP2
Price: 173.63 $
Specifications
| Brand | FAG |
| Item Number | N314-E-XL-TVP2 FAG |
| Manufacturer Part Number | 0167340840000 |
| Also known as |
N314-E-TVP2 |
| EAN | 4012801404099 |
| Category | Cylindrical Roller Bearing Single Row |
| Inner (d) MM | 70 |
| Outer (D) MM | 150 |
| Width (B) MM | 35 |
| Inner (d) Inch | 2.7559 |
| Outer (D) Inch | 5.9055 |
| Width (B) Inch | 1.378 |
| Weight (kg) | 2.73 kg |
| Bore | C - Cylindrical Bore |
| Seal | No Seal |
| Cage Type | P - Plastic Molded Cage |
| External Modification | No External Modification |
| Radial Internal Play | Cn Normal Internal Play |
| Precision | Standard Precision |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Width (b) mm | 35 |
| Radial Static Load Rating C0r (N) | 222000 |
| Radial Dynamic Load Rating Cr (N) | 242000 |
| Basic static load rating, radial (C 0r) | "222000.0000" |
| Limiting speed for grease lubrication (n G Grease) | 5400 |
| Limiting speed for oil lubrication (n G Oil) | 6300 |
| ECLASS number | 23-05-09-01 |
| ECLASS2 number | 23-05-09-01 |
| Medias description | Cylindrical roller bearing N3..-E-TVP2, with cage, single row, non-locating bearing, 0 ribs on outer ring, 2 rib on inner ring, type N3 |
| E | Increased Load Capacity |
| XL | X-Life |
| TVP2 | Solid Window Cage Made From Glass Fibre Reinforced Polyamide PA66. Roller Riding |
FAG 6314ZRN
2.59 kg
70x150x35 mm
FAG 6314N-M-C3
3.095 kg
70x150x35 mm
FAG 6314-N-C3
2.49 kg
70x150x35 mm
FAG 6314-J20AB-C3
2.52 kg
70x150x35 mm
FAG 6314-2Z-L207-C3
2.62 kg
70x150x35 mm
FAG 6314-C4
2.49 kg
70x150x35 mm
FAG 6314-MA-C3
3.125 kg
70x150x35 mm
FAG 6314-M-C3
3.125 kg
70x150x35 mm
FAG 6314-Z
2.585 kg
70x150x35 mm
FAG 6314-Z-N
2.59 kg
70x150x35 mm
FAG 6314-2Z-C4
2.615 kg
70x150x35 mm
FAG HC6314-2Z-L038-C3
2.615 kg
70x150x35 mm
FAG 6314-M
3.125 kg
70x150x35 mm
FAG 6314-2Z-C3
2.615 kg
70x150x35 mm
FAG 6314-J20AA-C3
2.62 kg
70x150x35 mm
FAG 6314-RSR
2.82 kg
70x150x35 mm
FAG 6314-2Z
2.615 kg
70x150x35 mm
FAG 6314-J20C-C3
2.52 kg
70x150x35 mm
FAG 6314-RSR-C3
2.82 kg
70x150x35 mm
FAG 6314-Z-N-C3
2.59 kg
70x150x35 mm
FAG 6314-2RSR
2.82 kg
70x150x35 mm
FAG 6314-C3
2.52 kg
70x150x35 mm
FAG 6314-H-2RSR-SN-C3
2.82 kg
70x150x35 mm
FAG 6314-Z-C3
2.59 kg
70x150x35 mm
FAG 6314-M-J20AA-C3
3.125 kg
70x150x35 mm
FAG 6314-M-C4
3.125 kg
70x150x35 mm
FAG 6314-2RSR-C3
2.82 kg
70x150x35 mm
FAG 6314-2Z-L237-C3
2.615 kg
70x150x35 mm
FAG 6314-N
2.49 kg
70x150x35 mm
FAG 6314-M-P6
3.125 kg
70x150x35 mm
FAG 6314-M-P6-C4
3.125 kg
70x150x35 mm
SKF 6314-2Z/C3WT
2.615 kg
70x150x35 mm
SKF 6314-2RS1/C3
2.82 kg
70x150x35 mm
SKF 6314MC/P52
3.125 kg
70x150x35 mm
