FAG 7314-B-XL-TVP-UA
Price: 149.64 $
Specifications
| Brand | FAG |
| Item Number | 7314-B-XL-TVP-UA FAG |
| Manufacturer Part Number | 0167262940000 |
| Also known as |
7314-B-TVP-UA |
| EAN | 4012801207720 |
| Category | Angular Contact Ball Bearing Single Row |
| Inner (d) MM | 70 |
| Outer (D) MM | 150 |
| Width (B) MM | 35 |
| Inner (d) Inch | 2.7559 |
| Outer (D) Inch | 5.9055 |
| Width (B) Inch | 1.378 |
| Weight (kg) | 2.65 kg |
| Seal | No Seal |
| Cage Type | P - Plastic Molded Cage |
| Precision | Standard Precision |
| Contact Angle | 40 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | UA - Universal design for fitting in pairs, bearing pair has slight axial internal clearance in O and X arrangements |
| Lubrication | Standard Lubrication |
| Width (b) mm | 35 |
| Radial Static Load Rating C0r (N) | 93000 |
| Radial Dynamic Load Rating Cr (N) | 126000 |
| Basic static load rating, radial (C 0r) | "93000.0000" |
| Limiting speed (n G) | 6000 |
| Reference speed (n u03d1r) | 4750 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Angular contact ball bearing 73..-B-XL-TVP, single row |
| B | 40° Contact Angle |
| XL | X-Life |
| TVP | Moulded Polyamide Window-Type Cage, Rolling Element Riding |
| UA | Universal Mounting, With O And X Configurations The Bearing Pair Has Small Axial Clearance |
