FAG 7308-B-XL-MP-P5-UL

FAG 7308-B-XL-MP-P5-UL
FAG 7308-B-XL-MP-P5-UL rulman resim 1
FAG 7308-B-XL-MP-P5-UL rulman resim 2
FAG 7308-B-XL-MP-P5-UL rulman resim 3
FAG 7308-B-XL-MP-P5-UL rulman resim 4
Price: 190.33 $
Specifications
Brand FAG
Item Number 7308-B-XL-MP-P5-UL FAG
Manufacturer Part Number 0191172050000
Also known as 7308-B-MP-P5-UL
EAN 4012801327602
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 40
Outer (D) MM 90
Width (B) MM 23
Inner (d) Inch 1.5748
Outer (D) Inch 3.5433
Width (B) Inch 0.9055
Weight (kg) 0.626 kg
Product Properties
Seal No Seal
Cage Type M - Brass Cage
Precision P5 Precision (Higher than P6)
Contact Angle 40 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 23
Radial Static Load Rating C0r (N) 34500
Radial Dynamic Load Rating Cr (N) 53000
Basic static load rating, radial (C 0r) "34500.0000"
Limiting speed (n G) 13500
Reference speed (n u03d1r) 7100
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearing 73..-B-XL-MP, single row
Suffix description
B 40° Contact Angle
XL X-Life
MP Machined Brass Cage, Window Type, Rolling Element Riding
P5 Dimensional And Running Accuracy To ISO Tolerance Class 5
UL Single Bearing, Universal, Light Preload
