FAG 7220-B-XL-MP-S1-UA
Price: 463.31 $
Specifications
| Brand | FAG |
| Item Number | 7220-B-XL-MP-S1-UA FAG |
| Manufacturer Part Number | 0191160040000 |
| Also known as |
7220-B-MP-S1-UA |
| EAN | 4012801283014 |
| Category | Angular Contact Ball Bearing Single Row |
| Inner (d) MM | 100 |
| Outer (D) MM | 180 |
| Width (B) MM | 34 |
| Inner (d) Inch | 3.937 |
| Outer (D) Inch | 7.0866 |
| Width (B) Inch | 1.3386 |
| Weight (kg) | 3.63 kg |
| Seal | No Seal |
| Cage Type | M - Brass Cage |
| Precision | Standard Precision |
| Contact Angle | 40 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | UA - Universal design for fitting in pairs, bearing pair has slight axial internal clearance in O and X arrangements |
| Lubrication | Standard Lubrication |
| Width (b) mm | 34 |
| Radial Static Load Rating C0r (N) | 124000 |
| Radial Dynamic Load Rating Cr (N) | 142000 |
| Basic static load rating, radial (C 0r) | "124000.0000" |
| Limiting speed (n G) | 6300 |
| Reference speed (n u03d1r) | 4250 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Angular contact ball bearings 72..-B, main dimensions to DIN 628-1, contact angle a = 40° |
| B | 40° Contact Angle |
| XL | X-Life |
| MP | Machined Brass Cage, Window Type, Rolling Element Riding |
| S1 | Stabilized For Operating Temperatures Up To +200 º C |
| UA | Universal Mounting, With O And X Configurations The Bearing Pair Has Small Axial Clearance |
