FAG 7220-B-XL-JP

FAG 7220-B-XL-JP
FAG 7220-B-XL-JP rulman resim 1
FAG 7220-B-XL-JP rulman resim 2
FAG 7220-B-XL-JP rulman resim 3
FAG 7220-B-XL-JP rulman resim 4
Price: 259.87 $
Specifications
Brand FAG
Item Number 7220-B-XL-JP FAG
Manufacturer Part Number 0191159700000
Also known as 7220-B-JP
EAN 4026677047793
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 100
Outer (D) MM 180
Width (B) MM 34
Inner (d) Inch 3.937
Outer (D) Inch 7.0866
Width (B) Inch 1.3386
Weight (kg) 3.19 kg
Product Properties
Seal No Seal
Cage Type S - Steel or Standard Cage
Precision Standard Precision
Contact Angle 40 degrees
Pairing No pairing
Axial Internal Clearance / Preload No Preload
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 34
Radial Static Load Rating C0r (N) 132000
Radial Dynamic Load Rating Cr (N) 148000
Basic static load rating, radial (C 0r) "132000.0000"
Limiting speed (n G) 4850
Reference speed (n u03d1r) 4200
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearings 72..-B, main dimensions to DIN 628-1, contact angle a = 40°
Suffix description
B 40° Contact Angle
XL X-Life
JP Pressed Steel Cage, Rolling Element Guided
