FAG 21314EK-TVPB
Price: 139.32 $
Specifications
| Brand | FAG |
| Item Number | 21314EK.TVPB FAG |
| Category | Spherical Roller Bearing |
| Inner (d) MM | 70 |
| Outer (D) MM | 150 |
| Width (B) MM | 35 |
| Inner (d) Inch | 2.7559 |
| Outer (D) Inch | 5.9055 |
| Width (B) Inch | 1.378 |
| Weight (kg) | 2.95 kg |
| Bore | K - 1:12 Tapered Bore (Standard for Most Types) |
| Lubrication Enhancement | W33 - Lubrication Groove and 3 Holes |
| Seal | No Seal |
| Cage Type | P - Plastic Molded Cage |
| Radial Internal Play | Cn Normal Internal Play |
| Precision | Standard Precision |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Vibrating Screen Execution | Non Vibrating Screen Execution |
| E | Maximum Capacity Design |
| K | Tapered Bore, Taper 1:12 |
| TVPB | Solid Window Cage Made From Glass Fibre Reinforced Polyamide, Guidance On Inner Ring |
