FAG 21314-E1-XL-TVPB-C3
Price: 125.38 $
Specifications
| Brand | FAG |
| Item Number | 21314-E1-XL-TVPB-C3 FAG |
| Manufacturer Part Number | 0190002430030 |
| Also known as |
21314-E1-TVPB-C3 |
| EAN | 4026677809445 |
| Category | Spherical Roller Bearing |
| Inner (d) MM | 70 |
| Outer (D) MM | 150 |
| Width (B) MM | 35 |
| Inner (d) Inch | 2.7559 |
| Outer (D) Inch | 5.9055 |
| Width (B) Inch | 1.378 |
| Weight (kg) | 2.95 kg |
| Bore | C - Cylindrical Bore |
| Lubrication Enhancement | W33 - Lubrication Groove and 3 Holes |
| Seal | No Seal |
| Cage Type | P - Plastic Molded Cage |
| Radial Internal Play | C3 Internal Play (Higher than Cn) |
| Precision | Standard Precision |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Vibrating Screen Execution | Non Vibrating Screen Execution |
| Width (b) mm | 35 |
| Radial Static Load Rating C0r (N) | 270000 |
| Radial Dynamic Load Rating Cr (N) | 250000 |
| Basic static load rating, radial (C 0r) | "270000.0000" |
| Limiting speed (n G) | 6200 |
| Reference speed (n u03d1r) | 3950 |
| ECLASS number | 23-05-09-11 |
| ECLASS2 number | 23-05-09-11 |
| Medias description | Spherical roller bearings 213..-E1, main dimensions to DIN 635-2 |
| E1 | Increased Capacity Design |
| XL | X-Life |
| TVPB | Solid Window Cage Made From Glass Fibre Reinforced Polyamide, Guidance On Inner Ring |
| C3 | Internal Clearance Larger Than Normal |
