FAG 21308-E1-XL-TVPB-C3

FAG 21308-E1-XL-TVPB-C3
FAG 21308-E1-XL-TVPB-C3 rulman resim 1
FAG 21308-E1-XL-TVPB-C3 rulman resim 2
FAG 21308-E1-XL-TVPB-C3 rulman resim 3
FAG 21308-E1-XL-TVPB-C3 rulman resim 4
FAG 21308-E1-XL-TVPB-C3 rulman resim 5
Price: 55.75 $
Specifications
Brand FAG
Item Number 21308-E1-XL-TVPB-C3 FAG
Manufacturer Part Number 0167022710030
Also known as 21308-E1-TVPB-C3
EAN 4026677805430
Category Spherical Roller Bearing
Weight and Dimensions
Inner (d) MM 40
Outer (D) MM 90
Width (B) MM 23
Inner (d) Inch 1.5748
Outer (D) Inch 3.5433
Width (B) Inch 0.9055
Weight (kg) 0.706 kg
Product Properties
Bore C - Cylindrical Bore
Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
Seal No Seal
Cage Type P - Plastic Molded Cage
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Width (b) mm 23
Radial Static Load Rating C0r (N) 107000
Radial Dynamic Load Rating Cr (N) 109000
Basic static load rating, radial (C 0r) "107000.0000"
Limiting speed (n G) 9800
Reference speed (n u03d1r) 5200
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 213..-E1, main dimensions to DIN 635-2
Suffix description
E1 Increased Capacity Design
XL X-Life
TVPB Solid Window Cage Made From Glass Fibre Reinforced Polyamide, Guidance On Inner Ring
C3 Internal Clearance Larger Than Normal
