SKF 7018ACD/P4ADBA Image 2
Visual product photo and picture of the product.
Price: 1,178.63 $
Specifications
Weight and Dimensions
| Inner (d) MM |
90 |
| Outer (D) MM |
140 |
| Width (B) MM |
48 |
| Inner (d) Inch |
3.5433 |
| Outer (D) Inch |
5.5118 |
| Width (B) Inch |
1.8898 |
| Weight (kg) |
2.3 kg
|
Product Properties
| Seal |
No Seal |
| Cage Type |
TB - Hard Fiber Cage |
| Precision |
P4 Precision (Higher than P5) |
| Contact Angle |
25 degrees |
| Pairing |
DB - O-arrangement, 2 |
| Axial Internal Clearance / Preload |
GA - Light Preload |
| Lubrication |
Standard Lubrication |
Suffix description
| ACD |
25° Contact Angle |
| P4A |
Dimensional Accuracy In Accordance With ISO Tolerance Class 4, Running Accuracy Better Than ISO Tolerance Class 4 |
| DBA |
Two Single Row Deep Groove Ball Bearings, Single Row Angular Contact Ball Bearings Or Single Row Tapered Roller Bearings Matched For Mounting In A Back-To-Back Arrangement, Light Preload |
