SKF 7018ACD/P4ADBA
Price: 1,178.63 $
Specifications
| Brand | SKF |
| Item Number | 7018ACD/P4ADBA SKF |
| Also known as |
EX90 7 CE3 DDL |
| EAN | 7316570384123 |
| Category | Angular Contact Ball Bearing Single Row |
| Inner (d) MM | 90 |
| Outer (D) MM | 140 |
| Width (B) MM | 48 |
| Inner (d) Inch | 3.5433 |
| Outer (D) Inch | 5.5118 |
| Width (B) Inch | 1.8898 |
| Weight (kg) | 2.3 kg |
| Seal | No Seal |
| Cage Type | TB - Hard Fiber Cage |
| Precision | P4 Precision (Higher than P5) |
| Contact Angle | 25 degrees |
| Pairing | DB - O-arrangement, 2 |
| Axial Internal Clearance / Preload | GA - Light Preload |
| Lubrication | Standard Lubrication |
| ACD | 25° Contact Angle |
| P4A | Dimensional Accuracy In Accordance With ISO Tolerance Class 4, Running Accuracy Better Than ISO Tolerance Class 4 |
| DBA | Two Single Row Deep Groove Ball Bearings, Single Row Angular Contact Ball Bearings Or Single Row Tapered Roller Bearings Matched For Mounting In A Back-To-Back Arrangement, Light Preload |
FAG HSS7018-C-T-P4S-DUL
2.76 kg
90x140x48 mm
FAG B7018-E-T-P4S-DUL
2.26 kg
90x140x48 mm
FAG B7018-C-T-P4S-DUL
2.28 kg
90x140x48 mm
FAG HCS7018-E-T-P4S-DUL
2.38 kg
90x140x48 mm
FAG B7018-C-T-P4S-DBL
2.28 kg
90x140x48 mm
SNFA EX90 7 CE1 DDM
2.3 kg
90x140x48 mm
SKF 7018ACD/P4ADGB
2.3 kg
90x140x48 mm
SKF 7018CD/P4ADGA
2.3 kg
90x140x48 mm
SKF 7018AC/P4DBB
2.3 kg
90x140x48 mm
SKF 7018CD/P4ADBB
2.3 kg
90x140x48 mm
SNFA EX90 7 CE3 7 CE1 TD35DAN
2.3 kg
90x140x48 mm
SKF 7018ACD/P4ADGA
2.3 kg
90x140x48 mm
RHP 7018A5TRDUMP3
2.3 kg
90x140x48 mm
NSK 7018ADB
2.36 kg
90x140x48 mm
NSK 7018A5TRDULP3
1.3 kg
90x140x48 mm
Nachi 7018CYDU/GLP4
2.3 kg
90x140x48 mm
NSK 7018CTRDULP3
2.3 kg
90x140x48 mm
NSK 7018A5TRDUMP3
2.3 kg
90x140x48 mm
NSK 7018CTRDUMP3
2.3 kg
90x140x48 mm
FAG XCB7018-EDLR-T-P4S-DUL
1.92 kg
90x140x48 mm
FAG B7018C-T-P4S-DUL
2.28 kg
90x140x48 mm
FAG XCS7018-E-T-P4S-DTL
2.44 kg
90x140x48 mm
SKF S7018ACD/P4ADBA
2.34 kg
90x140x48 mm
RHP 7018C TR DUM P3
2.3 kg
90x140x48 mm
RHP 7018E T DUL P4
2.3 kg
90x140x48 mm
RHP 7018A5TRDULP3
1.3 kg
90x140x48 mm
SKF 7018ACD/P4ADBB
2.3 kg
90x140x48 mm
SKF 7018CD/P4ADBC
2.3 kg
90x140x48 mm
SKF 7018CD/P4ADGB
2.3 kg
90x140x48 mm
NSK 7018A5 TR DUL P3
1.3 kg
90x140x48 mm
Fafnir 3MM9118WIDUL
2.3 kg
90x140x48 mm
NSK 7018C TR DUL P3
2.3 kg
90x140x48 mm
SNR 7018C DB J85 M27
2.32 kg
90x140x48 mm
NTN SF1880DBCS34P4
2.71 kg
90x140x48 mm
NSK 7018A5 TR DUM P3
2.3 kg
90x140x48 mm
