INA ZKLR1547-2RS-A Image 4
Visual product photo and picture of the product.
Price: 206.98 $
Specifications
Weight and Dimensions
| Inner (d) MM |
15 |
| Outer (D) MM |
38,45 |
| Width (B) MM |
24 |
| Inner (d) Inch |
0.5906 |
| Outer (D) Inch |
1.5138 |
| Width (B) Inch |
0.9449 |
| Weight (kg) |
0.14 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
2RS - Rubber Seal on Two Sides |
| Cage Type |
S - Steel or Standard Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
Cn Normal Internal Play |
| Precision |
Standard Precision |
| Lubrication |
Standard Lubrication |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring |
Split inner ring |
Data from Schaeffler (medias)
| Outside diameter bearing pot (D) mm |
38,45 |
| Radial Static Load Rating C0r (N) |
10700 |
| Width inner ring (B) mm |
22 |
| Radial Dynamic Load Rating Cr (N) |
16700 |
| Axial Static Load Rating C0a (N) |
22400 |
| Axial Dynamic Load Rating Ca (N) |
16400 |
| ECLASS number |
23-05-16-02 |
| ECLASS2 number |
23-05-16-02 |
| Medias description |
Angular contact ball bearing units ZKLR..-2RS, double direction, for screw mounting, lip seals on both sides |
Suffix description
| 2RS |
Lip Seal At Both Sides Of The Bearing, Axial Fitting |
| A |
The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307) |
