INA ZKLR1547-2RS-A

Specifications

Brand	INA
Item Number	ZKLR1547-2RS-A INA
Manufacturer Part Number	0628366170000
EAN	4012802825756
Category	Angular Contact Ball Bearing Double Row

Weight and Dimensions

Inner (d) MM	15
Outer (D) MM	38,45
Width (B) MM	24
Inner (d) Inch	0.5906
Outer (D) Inch	1.5138
Width (B) Inch	0.9449
Weight (kg)	0.14 kg

Product Properties

Bore	C - Cylindrical Bore
Seal	2RS - Rubber Seal on Two Sides
Cage Type	S - Steel or Standard Cage
External Modification	No External Modification
Radial Internal Play	Cn Normal Internal Play
Precision	Standard Precision
Lubrication	Standard Lubrication
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring	Split inner ring

Data from Schaeffler (medias)

Outside diameter bearing pot (D) mm	38,45
Radial Static Load Rating C0r (N)	10700
Width inner ring (B) mm	22
Radial Dynamic Load Rating Cr (N)	16700
Axial Static Load Rating C0a (N)	22400
Axial Dynamic Load Rating Ca (N)	16400
ECLASS number	23-05-16-02
ECLASS2 number	23-05-16-02
Medias description	Angular contact ball bearing units ZKLR..-2RS, double direction, for screw mounting, lip seals on both sides

Suffix description

2RS

Lip Seal At Both Sides Of The Bearing, Axial Fitting

A

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
