INA TCJ40-XL-N Image 3

Visual product photo and picture of the product.

INA TCJ40-XL-N bearing image 3
INA TCJ40-XL-N bearing image 1
INA TCJ40-XL-N bearing image 2
INA TCJ40-XL-N bearing image 3
Price: 68.75 $
Specifications
Brand INA
Item Number TCJ40-XL-N INA
Manufacturer Part Number 0008568510000
Also known as TCJ40-N
EAN 4012802799118
Category Housing and Bearing (assembly)
Weight and Dimensions
Inner (d) MM 40
Outer (D) MM 130
Width (B) MM 59,1
Inner (d) Inch 1.5748
Outer (D) Inch 5.1181
Width (B) Inch 2.3268
Weight (kg) 2.02 kg
Product Properties
Seal 2T - Two T-seals
Lubrication Standard Lubrication
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Flange width (L) mm 130
Total height unit (U) mm 59,1
Radial Static Load Rating C0r (N) 19800
Radial Dynamic Load Rating Cr (N) 34500
Basic static load rating, radial (C 0r) "19800.0000"
ECLASS number 23-05-16-02
ECLASS2 number 23-05-16-02
Medias description Housing units TCJ, four-bolt flanged housing units, cast iron, eccentric locking collar, T seals
Suffix description
XL X-Life
N Cast Iron Housing With Undercut Slot For End Caps
