INA TCJ40-XL-N

Specifications

Brand	INA
Item Number	TCJ40-XL-N INA
Manufacturer Part Number	0008568510000
Also known as	TCJ40-N
EAN	4012802799118
Category	Housing and Bearing (assembly)

Weight and Dimensions

Inner (d) MM	40
Outer (D) MM	130
Width (B) MM	59,1
Inner (d) Inch	1.5748
Outer (D) Inch	5.1181
Width (B) Inch	2.3268
Weight (kg)	2.02 kg

Product Properties

Seal	2T - Two T-seals
Lubrication	Standard Lubrication
Special Treatment	No Special Treatment

Data from Schaeffler (medias)

Flange width (L) mm	130
Total height unit (U) mm	59,1
Radial Static Load Rating C0r (N)	19800
Radial Dynamic Load Rating Cr (N)	34500
Basic static load rating, radial (C 0r)	"19800.0000"
ECLASS number	23-05-16-02
ECLASS2 number	23-05-16-02
Medias description	Housing units TCJ, four-bolt flanged housing units, cast iron, eccentric locking collar, T seals

Suffix description

XL	X-Life
N	Cast Iron Housing With Undercut Slot For End Caps
