INA KWVE35-WL-V0-G3 Image 3
Visual product photo and picture of the product.
Price: 213.53 $
Specifications
Weight and Dimensions
| Inner (d) MM |
90 |
| Outer (D) MM |
162 |
| Width (B) MM |
140,2 |
| Inner (d) Inch |
3.5433 |
| Outer (D) Inch |
6.378 |
| Width (B) Inch |
5.5197 |
| Weight (kg) |
4.11 kg
|
Product Properties
Data from Schaeffler (medias)
| Width carriage (B) mm |
162 |
| Overall length carriage (L) mm |
140,2 |
| Dynamic load rating (C) |
47500 |
| Static load rating (C 0) |
100000 |
| Static moment rating about X axis (M 0x) |
5550 |
| Static moment rating about Y axis (M 0y) |
1890 |
| Static moment rating about Z axis (M 0z) |
1890 |
| ECLASS number |
23-30-04-90 |
| ECLASS2 number |
23-30-04-90 |
| Medias description |
Carriages KWVE..-WL, wide, long carriage for linear recirculating ball bearing and guideway assembly |
Suffix description
| WL |
Wide, Long Carriage |
| V0 |
Little To No Preload |
| G3 |
Precision Class 3 |
