INA KWVE35-WL-V0-G3

INA KWVE35-WL-V0-G3
INA KWVE35-WL-V0-G3 rulman resim 1
INA KWVE35-WL-V0-G3 rulman resim 2
INA KWVE35-WL-V0-G3 rulman resim 3
INA KWVE35-WL-V0-G3 rulman resim 4
INA KWVE35-WL-V0-G3 rulman resim 5
Price: 213.53 $
Specifications
Brand INA
Item Number KWVE35-WL-V0-G3 INA
Manufacturer Part Number 0328805960140
Also known as KWVE35-WL-G3-V0
EAN 4054366357304
Category Linear Plain Bearing Unit
Weight and Dimensions
Inner (d) MM 90
Outer (D) MM 162
Width (B) MM 140,2
Inner (d) Inch 3.5433
Outer (D) Inch 6.378
Width (B) Inch 5.5197
Weight (kg) 4.11 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Width carriage (B) mm 162
Overall length carriage (L) mm 140,2
Dynamic load rating (C) 47500
Static load rating (C 0) 100000
Static moment rating about X axis (M 0x) 5550
Static moment rating about Y axis (M 0y) 1890
Static moment rating about Z axis (M 0z) 1890
ECLASS number 23-30-04-90
ECLASS2 number 23-30-04-90
Medias description Carriages KWVE..-WL, wide, long carriage for linear recirculating ball bearing and guideway assembly
Suffix description
WL Wide, Long Carriage
V0 Little To No Preload
G3 Precision Class 3
