INA GNE90-KRR-B-FA107 Image 5
Visual product photo and picture of the product.
Price: 530.94 $
Specifications
Weight and Dimensions
| Inner (d) MM |
90 |
| Outer (D) MM |
190 |
| Width (B) MM |
101 |
| Inner (d) Inch |
3.5433 |
| Outer (D) Inch |
7.4803 |
| Width (B) Inch |
3.9764 |
| Weight (kg) |
9.3 kg
|
Product Properties
| Seal |
2F - Standard Seal for Y-bearings |
| Lubrication |
Standard Lubrication |
| Special Treatment |
I - Lubr Holes on Locating Side |
Data from Schaeffler (medias)
| Outside diameter (D SP) mm |
190 |
| Width (b) mm |
77,5 |
| Locking collar total width (B 1) mm |
101 |
| Radial Static Load Rating C0r (N) |
107000 |
| Radial Dynamic Load Rating Cr (N) |
151000 |
| Basic static load rating, radial (C 0r) |
"107000.0000" |
| ECLASS number |
23-05-08-02 |
| ECLASS2 number |
23-05-08-02 |
| Medias description |
Radial insert ball bearing GNE..-KRR-B |
Suffix description
| KRR |
Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder) |
| B |
Bearing With Spherical Outer Ring |
| FA107 |
Bearing With Lubrication Holes On The Locating Side |
