INA GNE90-KRR-B-FA107

Specifications

Brand	INA
Item Number	GNE90-KRR-B-FA107 INA
Manufacturer Part Number	0004880620000
EAN	4012802784886
Category	Bearings for Housings

Weight and Dimensions

Inner (d) MM	90
Outer (D) MM	190
Width (B) MM	101
Inner (d) Inch	3.5433
Outer (D) Inch	7.4803
Width (B) Inch	3.9764
Weight (kg)	9.3 kg

Product Properties

Seal	2F - Standard Seal for Y-bearings
Lubrication	Standard Lubrication
Special Treatment	I - Lubr Holes on Locating Side

Data from Schaeffler (medias)

Outside diameter (D SP) mm	190
Width (b) mm	77,5
Locking collar total width (B 1) mm	101
Radial Static Load Rating C0r (N)	107000
Radial Dynamic Load Rating Cr (N)	151000
Basic static load rating, radial (C 0r)	"107000.0000"
ECLASS number	23-05-08-02
ECLASS2 number	23-05-08-02
Medias description	Radial insert ball bearing GNE..-KRR-B

Suffix description

KRR	Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder)
B	Bearing With Spherical Outer Ring
FA107	Bearing With Lubrication Holes On The Locating Side
