INA GNE100-XL-KRR-B Image 2
Visual product photo and picture of the product.
Price: 732.38 $
Specifications
Weight and Dimensions
| Inner (d) MM |
100 |
| Outer (D) MM |
215 |
| Width (B) MM |
109,4 |
| Inner (d) Inch |
3.937 |
| Outer (D) Inch |
8.4646 |
| Width (B) Inch |
4.3071 |
| Weight (kg) |
12.3 kg
|
Product Properties
| Seal |
2F - Standard Seal for Y-bearings |
| Lubrication |
Standard Lubrication |
| Special Treatment |
No Special Treatment |
Data from Schaeffler (medias)
| Outside diameter (D SP) mm |
215 |
| Width (b) mm |
86 |
| Locking collar total width (B 1) mm |
109,4 |
| Radial Static Load Rating C0r (N) |
141000 |
| Radial Dynamic Load Rating Cr (N) |
184000 |
| Basic static load rating, radial (C 0r) |
"140000.0000" |
| ECLASS number |
23-05-08-02 |
| ECLASS2 number |
23-05-08-02 |
| Medias description |
Radial insert ball bearings GNE..-KRR-B, spherical outer ring, location by eccentric locking collar, R seals on both sides |
Suffix description
| XL |
X-Life |
| KRR |
Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder) |
| B |
Bearing With Spherical Outer Ring |
