INA GNE100-XL-KRR-B

Specifications

Brand	INA
Item Number	GNE100-XL-KRR-B INA
Manufacturer Part Number	0008839480000
Also known as	GNE100-KRR-B
EAN	4012802809084
Category	Bearings for Housings

Weight and Dimensions

Inner (d) MM	100
Outer (D) MM	215
Width (B) MM	109,4
Inner (d) Inch	3.937
Outer (D) Inch	8.4646
Width (B) Inch	4.3071
Weight (kg)	12.3 kg

Product Properties

Seal	2F - Standard Seal for Y-bearings
Lubrication	Standard Lubrication
Special Treatment	No Special Treatment

Data from Schaeffler (medias)

Outside diameter (D SP) mm	215
Width (b) mm	86
Locking collar total width (B 1) mm	109,4
Radial Static Load Rating C0r (N)	141000
Radial Dynamic Load Rating Cr (N)	184000
Basic static load rating, radial (C 0r)	"140000.0000"
ECLASS number	23-05-08-02
ECLASS2 number	23-05-08-02
Medias description	Radial insert ball bearings GNE..-KRR-B, spherical outer ring, location by eccentric locking collar, R seals on both sides

Suffix description

XL	X-Life
KRR	Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder)
B	Bearing With Spherical Outer Ring
