INA GNE100-KRR-B-FA107

Specifications

Brand	INA
Item Number	GNE100-KRR-B-FA107 INA
Manufacturer Part Number	0004880890000
EAN	4012802784879
Category	Bearings for Housings

Weight and Dimensions

Inner (d) MM	100
Outer (D) MM	215
Width (B) MM	109,4
Inner (d) Inch	3.937
Outer (D) Inch	8.4646
Width (B) Inch	4.3071
Weight (kg)	12.3 kg

Product Properties

Seal	2F - Standard Seal for Y-bearings
Lubrication	Standard Lubrication
Special Treatment	I - Lubr Holes on Locating Side

Data from Schaeffler (medias)

Outside diameter (D SP) mm	215
Width (b) mm	86
Locking collar total width (B 1) mm	109,4
Radial Static Load Rating C0r (N)	141000
Radial Dynamic Load Rating Cr (N)	184000
Basic static load rating, radial (C 0r)	"131000.0000"
ECLASS number	23-05-08-02
ECLASS2 number	23-05-08-02
Medias description	Radial insert ball bearing GNE..-KRR-B

Suffix description

KRR	Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder)
B	Bearing With Spherical Outer Ring
FA107	Bearing With Lubrication Holes On The Locating Side
