INA GE120-XL-KRR-B Image 3
Visual product photo and picture of the product.
Price: 548.35 $
Specifications
Weight and Dimensions
| Inner (d) MM |
120 |
| Outer (D) MM |
215 |
| Width (B) MM |
81 |
| Inner (d) Inch |
4.7244 |
| Outer (D) Inch |
8.4646 |
| Width (B) Inch |
3.189 |
| Weight (kg) |
6.93 kg
|
Product Properties
| Seal |
2F - Standard Seal for Y-bearings |
| Lubrication |
Standard Lubrication |
| Special Treatment |
No Special Treatment |
Data from Schaeffler (medias)
| Outside diameter (D SP) mm |
215 |
| Width (b) mm |
63,5 |
| Locking collar total width (B 1) mm |
81 |
| Radial Static Load Rating C0r (N) |
131000 |
| Radial Dynamic Load Rating Cr (N) |
165000 |
| Basic static load rating, radial (C 0r) |
"131000.0000" |
| ECLASS number |
23-05-08-02 |
| ECLASS2 number |
23-05-08-02 |
| Medias description |
Radial insert ball bearing GE..-XL-KRR-B |
Suffix description
| XL |
X-Life |
| KRR |
Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder) |
| B |
Bearing With Spherical Outer Ring |
