INA GE120-XL-KRR-B

Specifications

Brand	INA
Item Number	GE120-XL-KRR-B INA
Manufacturer Part Number	0008777510000
Also known as	GE120-KRR-B
EAN	4012802794953
Category	Bearings for Housings

Weight and Dimensions

Inner (d) MM	120
Outer (D) MM	215
Width (B) MM	81
Inner (d) Inch	4.7244
Outer (D) Inch	8.4646
Width (B) Inch	3.189
Weight (kg)	6.93 kg

Product Properties

Seal	2F - Standard Seal for Y-bearings
Lubrication	Standard Lubrication
Special Treatment	No Special Treatment

Data from Schaeffler (medias)

Outside diameter (D SP) mm	215
Width (b) mm	63,5
Locking collar total width (B 1) mm	81
Radial Static Load Rating C0r (N)	131000
Radial Dynamic Load Rating Cr (N)	165000
Basic static load rating, radial (C 0r)	"131000.0000"
ECLASS number	23-05-08-02
ECLASS2 number	23-05-08-02
Medias description	Radial insert ball bearing GE..-XL-KRR-B

Suffix description

XL	X-Life
KRR	Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder)
B	Bearing With Spherical Outer Ring
