INA GAL17-UK Image 3
Visual product photo and picture of the product.
Price: 41.27 $
Specifications
| Brand |
INA
|
| Item Number |
GAL17-UK INA
|
| Manufacturer Part Number |
0066330990000 |
| Also known as |
SAL17C
|
| EAN |
4012802523829 |
| Category |
Rod End
|
Weight and Dimensions
| Inner (d) MM |
17 |
| Outer (D) MM |
46 |
| Width (B) MM |
14 |
| Inner (d) Inch |
0.6693 |
| Outer (D) Inch |
1.811 |
| Width (B) Inch |
0.5512 |
| Weight (kg) |
0.17 kg
|
Product Properties
| Seal |
No Seal |
| Contact Material |
Steel on PTFE |
Data from Schaeffler (medias)
| Outside diameter bearing (D) mm |
30 |
| Outer eye diameter (d 2) mm |
46 |
| Radial Static Load Rating C0r (N) |
56500 |
| Width inner ring (B) mm |
14 |
| Radial Dynamic Load Rating Cr (N) |
22500 |
| Basic static load rating, radial (C 0r) |
"56500.0000" |
| Total length external thread rod (l 2) mm |
92 |
| ECLASS number |
23-05-01-05 |
| ECLASS2 number |
23-05-01-05 |
| Medias description |
Rod end with external thread, left hand thread, maintenance-free, sliding layer: PTFE composite, DIN ISO 12240-4, dimension series E, type M, inner ring curved surface with hard chromium coating, open design |
Suffix description
| UK |
Sliding Contact Surface Hard Chromium/PTFE Composite |
