INA GAL17-UK

INA GAL17-UK
INA GAL17-UK rulman resim 1
INA GAL17-UK rulman resim 2
INA GAL17-UK rulman resim 3
INA GAL17-UK rulman resim 4
Price: 41.27 $
Specifications
Brand INA
Item Number GAL17-UK INA
Manufacturer Part Number 0066330990000
Also known as SAL17C
EAN 4012802523829
Category Rod End
Weight and Dimensions
Inner (d) MM 17
Outer (D) MM 46
Width (B) MM 14
Inner (d) Inch 0.6693
Outer (D) Inch 1.811
Width (B) Inch 0.5512
Weight (kg) 0.17 kg
Product Properties
Seal No Seal
Contact Material Steel on PTFE
Data from Schaeffler (medias)
Outside diameter bearing (D) mm 30
Outer eye diameter (d 2) mm 46
Radial Static Load Rating C0r (N) 56500
Width inner ring (B) mm 14
Radial Dynamic Load Rating Cr (N) 22500
Basic static load rating, radial (C 0r) "56500.0000"
Total length external thread rod (l 2) mm 92
ECLASS number 23-05-01-05
ECLASS2 number 23-05-01-05
Medias description Rod end with external thread, left hand thread, maintenance-free, sliding layer: PTFE composite, DIN ISO 12240-4, dimension series E, type M, inner ring curved surface with hard chromium coating, open design
Suffix description
UK Sliding Contact Surface Hard Chromium/PTFE Composite
