INA GAKL12-PB-A Image 3
Visual product photo and picture of the product.
Price: 30.83 $
Specifications
Weight and Dimensions
| Inner (d) MM |
12 |
| Outer (D) MM |
33 |
| Width (B) MM |
16 |
| Inner (d) Inch |
0.4724 |
| Outer (D) Inch |
1.2992 |
| Width (B) Inch |
0.6299 |
| Weight (kg) |
0.085 kg
|
Product Properties
| Seal |
No Seal |
| Contact Material |
Steel on Bronze |
Data from Schaeffler (medias)
| Outside diameter bearing (D) mm |
26 |
| Radial Static Load Rating C0r (N) |
20800 |
| Width inner ring (B) mm |
16 |
| Radial Dynamic Load Rating Cr (N) |
13300 |
| Basic static load rating, radial (C 0r) |
"20800.0000" |
| ECLASS number |
23-05-01-05 |
| ECLASS2 number |
23-05-01-05 |
| Medias description |
Rod end with external thread, left hand thread, requiring maintenance, sliding contact surface: steel/bronze, DIN ISO 12240-4, dimension series K, type M, open design |
Suffix description
| PB |
Sliding Contact Surface Is Steel/Bronze |
| A |
The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307) |
