INA GAKL12-PB-A

Price: 30.83 $

Specifications

Brand	INA
Item Number	GAKL12-PB-A INA
Manufacturer Part Number	0065516610000
EAN	4012802521993
Category	Rod End

Weight and Dimensions

Inner (d) MM	12
Outer (D) MM	33
Width (B) MM	16
Inner (d) Inch	0.4724
Outer (D) Inch	1.2992
Width (B) Inch	0.6299
Weight (kg)	0.085 kg

Product Properties

Seal	No Seal
Contact Material	Steel on Bronze

Data from Schaeffler (medias)

Outside diameter bearing (D) mm	26
Radial Static Load Rating C0r (N)	20800
Width inner ring (B) mm	16
Radial Dynamic Load Rating Cr (N)	13300
Basic static load rating, radial (C 0r)	"20800.0000"
ECLASS number	23-05-01-05
ECLASS2 number	23-05-01-05
Medias description	Rod end with external thread, left hand thread, requiring maintenance, sliding contact surface: steel/bronze, DIN ISO 12240-4, dimension series K, type M, open design

Suffix description

Sliding Contact Surface Is Steel/Bronze

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
