INA CSXAA015-TV

Specifications

Brand	INA
Item Number	CSXAA015-TV INA
Manufacturer Part Number	0008232010000
Also known as	6000046
EAN	4054362038849
Category	Four Point Contact Ball Bearing

Weight and Dimensions

Inner (d) MM	38,1
Outer (D) MM	47,625
Width (B) MM	4,7625
Inner (d) Inch	1.5
Outer (D) Inch	1.875
Width (B) Inch	0.1875
Weight (kg)	0.02 kg

Product Properties

Seal	No Seal
Cage Type	P - Plastic Molded Cage
External Modification	No External Modification
Radial Internal Play	Cn Normal Internal Play
Precision	ABEC.1 Tolerances
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring	Standard

Data from Schaeffler (medias)

Width (b) mm	4,763
Radial Static Load Rating C0r (N)	2700
Radial Dynamic Load Rating Cr (N)	2700
Basic static load rating, radial (C 0r)	"2700.0000"
ECLASS number	23-05-08-03
ECLASS2 number	23-05-08-03
Medias description	Thin Section Bearing CSXAA..-TV, four-point contact bearing

Suffix description

TV	Solid Cage Of Glass-Fibre Reinforced Polyamide, Ball Riding
