INA CSCAA015-TV-HLE

Specifications

Brand	INA
Item Number	CSCAA015-TV-HLE INA
Manufacturer Part Number	0050500490000
Also known as	6000046
EAN	4054362037125
Category	Deep Groove Ball Bearings Single Row

Weight and Dimensions

Inner (d) MM	38,1
Outer (D) MM	47,625
Width (B) MM	4,7625
Inner (d) Inch	1.5
Outer (D) Inch	1.875
Width (B) Inch	0.1875
Weight (kg)	0.02 kg

Product Properties

Bore	C - Cylindrical Bore
Seal	No Seal
Cage Type	P - Plastic Molded Cage
External Modification	No External Modification
Radial Internal Play	Cn Normal Internal Play
Precision	ABEC.1 Tolerances
Lubrication	Standard Lubrication
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C
Special Treatment	No Special Treatment

Data from Schaeffler (medias)

Width (b) mm	4,763
Radial Static Load Rating C0r (N)	1540
Radial Dynamic Load Rating Cr (N)	2020
Basic static load rating, radial (C 0r)	"1540.0000"
Limiting speed (n G)	14100
ECLASS number	23-05-08-01
ECLASS2 number	23-05-08-01
Medias description	Thin Section Bearing CSCAA..-TV, deep groove ball bearing

Suffix description

TV	Solid Cage Of Glass-Fibre Reinforced Polyamide, Ball Riding
HLE	Factory Location Code, No Additional Meaning. Can Be Used As Standard
