INA CSEAA015-TV-HLE

Specifications

Brand	INA
Item Number	CSEAA015-TV-HLE INA
Manufacturer Part Number	0034980180000
Also known as	6000046
EAN	4054362037989
Category	Angular Contact Ball Bearing Single Row

Weight and Dimensions

Inner (d) MM	38,1
Outer (D) MM	47,625
Width (B) MM	4,7625
Inner (d) Inch	1.5
Outer (D) Inch	1.875
Width (B) Inch	0.1875
Weight (kg)	0.02 kg

Product Properties

Seal	No Seal
Cage Type	P - Plastic Molded Cage
Precision	Standard Precision
Contact Angle	30 degrees
Pairing	No pairing
Axial Internal Clearance / Preload	No Preload
Lubrication	Standard Lubrication

Data from Schaeffler (medias)

Width (b) mm	4,763
Radial Static Load Rating C0r (N)	1860
Radial Dynamic Load Rating Cr (N)	2050
Basic static load rating, radial (C 0r)	"1860.0000"
ECLASS number	23-05-08-03
ECLASS2 number	23-05-08-03
Medias description	Thin Section Bearing CSEAA..-TV, angular contact ball bearing

Suffix description

TV	Solid Cage Of Glass-Fibre Reinforced Polyamide, Ball Riding
HLE	Factory Location Code, No Additional Meaning. Can Be Used As Standard
