INA 3809-2RS

Specifications

Brand	INA
Item Number	3809-2RS INA
Manufacturer Part Number	0009931070000
EAN	4012802631517
Category	Angular Contact Ball Bearing Double Row

Weight and Dimensions

Inner (d) MM	45
Outer (D) MM	58
Width (B) MM	10
Inner (d) Inch	1.7717
Outer (D) Inch	2.2835
Width (B) Inch	0.3937
Weight (kg)	0.053 kg

Product Properties

Bore	C - Cylindrical Bore
Seal	2RS - Rubber Seal on Two Sides
Cage Type	P - Plastic Molded Cage
External Modification	No External Modification
Radial Internal Play	Cn Normal Internal Play
Precision	Standard Precision
Lubrication	Standard Lubrication
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring	Standard

Data from Schaeffler (medias)

Width (b) mm	10
Radial Static Load Rating C0r (N)	8100
Radial Dynamic Load Rating Cr (N)	7000
Basic static load rating, radial (C 0r)	"8100.0000"
Limiting speed (n G)	5500
ECLASS number	23-05-08-03
ECLASS2 number	23-05-08-03
Medias description	Angular contact ball bearings 38..-B-2RS, Double row design, lip seals on both sides, contact angle a = 25°

Suffix description

2RS	Lip Seal At Both Sides Of The Bearing, Axial Fitting
