INA 3809-2Z

Specifications

Brand	INA
Item Number	3809-2Z INA
Manufacturer Part Number	0009931310000
EAN	4012802029192
Category	Angular Contact Ball Bearing Double Row

Weight and Dimensions

Inner (d) MM	45
Outer (D) MM	58
Width (B) MM	10
Inner (d) Inch	1.7717
Outer (D) Inch	2.2835
Width (B) Inch	0.3937
Weight (kg)	0.053 kg

Product Properties

Bore	C - Cylindrical Bore
Seal	ZZ/2Z - Steel Seal on Two Sides
Cage Type	P - Plastic Molded Cage
External Modification	No External Modification
Radial Internal Play	Cn Normal Internal Play
Precision	Standard Precision
Lubrication	Standard Lubrication
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring	Standard

Data from Schaeffler (medias)

Width (b) mm	10
Radial Static Load Rating C0r (N)	8100
Radial Dynamic Load Rating Cr (N)	7000
Basic static load rating, radial (C 0r)	"8100.0000"
Limiting speed (n G)	9300
Reference speed (n u03d1r)	5700
ECLASS number	23-05-08-03
ECLASS2 number	23-05-08-03
Medias description	Angular contact ball bearing 38..-B-2RZ-TVH, double row, 1 inner ring

Suffix description

2Z	Gap Seals At Both Sides Of The Bearing
